Transformer Health Monitoring

Code 384 Transformer Health Monitoring

6,800.00 4,800.00

Transformers are a vital part of the transmission and distribution system. Monitoring transformers for problems before they occur can prevent faults that are costly to repair and result in a loss of service. The performance of prototype model developed is tested at laboratory for monitoring various parameters like transformer Over voltage and Under Voltage, Over current and Under current, Over temperature , Less Oil etc.

Kits DescriptionPrice
If You Are An Enthusiast

Do It Yourself kit
Ready-made Project, PCB, Components, Circuit Diagram, Program, Report, Explanatory Video

7,700.00 5,700.00
If You Are Short On Time

Ready-made Kit
Ready-made Project, Circuit Diagram, Program, Report, Explanatory Video

6,800.00 4,800.00
For Institutions

Project kit
PCB, Components, Circuit Diagram, Program, Report, Explanatory Video

6,200.00 4,200.00
For Documentation

Documentation
Circuit Diagram, Program, Report, Explanatory Video

2,000.00 1,000.00
For PCB

PCB
PCB, Components, Circuit Diagram

2,100.00 1,000.00

Description

In this project, a “Transformer Health Monitoring using Arduino” main attention is to reduced or overcome the fault occurred in the transformer. To prevent the transformer from the fault due to the over- currents, temperature rise in transformers oil and over voltage we used buzzer  and sensor. In this protective methodology is implemented by using of Arduino controller. It is cost powerful device and high speed of operation with greater accuracy. Load current and transformer temperature are continuously monitored or sense by the controller. If supply voltage and load current crosses the threshold value which are previously set values in programed and gives the indication by turning on buzzer. And all parameters are displayed on lcd.

HIGHLIGHTS

  • Transformer Protection.
  • Automatic Detection.
  • Parameters-Voltage, Current, Oil Level, Temperature

BLOCK DIAGRAM

HARDWARE REQUIREMENTS

  • Arduino
  • Transformer
  • LCD
  • Buzzer
  • Diode
  • Capacitor
  • Resistor
  • Load
  • LM35
  • Pot
  • Ultrasonic Sensor
  • Relay

SOFTWARE REQUIREMENTS

  • Arduino
  • Eagle
