RFID BASED GATE OPENING

Code 22 RFID BASED GATE OPENING

5.00 out of 5
(2 customer reviews)

7,500.00 5,000.00

Ready-made Project

If You Are Short On Time
7,500.00 5,000.00
Add to cart - OR - See more options

RFID based gate opening uses a microcontroller along with circuits monitoring entry and exit of cars. The vehicle owners are allowed an entry only when their RFID card is swiped. display indication besides indicating the gate is open or gate is close.

Kits DescriptionPrice
Ready-made Project + DIY Project Kit
If You Are An Enthusiast
Ready-made project kit, One more extra bare PCB solderable components for extra PCB, All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, and One year warranty. 8,700.00 6,800.00
Ready-made Project
If You Are Short On Time
Ready-made project kit - All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, One year warranty. 7,500.00 5,000.00
DIY Project Kit
For Institutions
DIY KIT - Bare PCB, solderable components, external all components, All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, 6,500.00 4,800.00
For Documentation
(Report, PPT, Circuit diagram, Program code, Explanatory Video). Audio and video call support. 3,000.00 2,000.00

Description

RFID based gate opening uses a microcontroller along with circuits monitoring entry and exit of cars. The vehicle owners are allowed an entry only when their RFID card is swiped. display indication besides indicating the gate is open or gate is close.

.Example is shown for 2 cards but it can be extended to many numbers. An arrangement operates the entry and exit motors operating clockwise and anticlockwise for opening and closing. A buzzer sound comes while the card is swiped. Upon every entry of a vehicle the authorized card matched with stored data and operation will perform gate open and close if the card is not authorized then it displays card details not found . A standard power supply is used. A LCD displays the status. A switch is used in place of RFID for minimizing the project cost.

HIGHLIGHTS

  • Microcontroller is used
  • RFID reader is interfaced with controller
  • Athorized card is compaired and allowed
  • DC motor is drived as gate

BLOCK DIAGRAM

HARDWARE REQUIREMENTS

  • Microcontroller
  • RFID Reader
  • RFID Cards
  • L293D IC
  • DC Motor
  • LCD Display
  • Transformer

SOFTWARE REQUIREMENTS

  • Keil
  • Eagle
