DIGITAL CLOCK USING PIC CONTROLLER

Code 130 DIGITAL CLOCK USING PIC CONTROLLER

4,700.00 3,500.00

The main goal of this project is Digital clock using PIC micro-controller. In this system, a large number of switches are activated to adjust the time and date.

Kits DescriptionPrice
Ready-made Project + DIY Project Kit
If You Are An Enthusiast

Do It Yourself Kit
Ready-made Project,PCB,Components,Circuit Diagram,Program,Report,Explanatory Video

5,900.00 3,800.00
Ready-made Project
If You Are Short On Time

Ready-made Kit
Ready-made Project,Circuit Diagram,Program,Report,Explanatory Video

4,700.00 3,500.00
DIY Project Kit
For Institutions

Project Kit
PCB,Components,Circuit Diagram,Program,Report,Explanatory Video

3,500.00 3,200.00
For Documentation

Documentation
Circuit diagram,Program,Report,Explanatory Video

2,100.00 1,200.00
For PCB

PCB
PCB,Circuit Diagram

1,700.00 900.00

Description

The main goal of this project is Digital clock using PIC microcontroller. In this system, a large number of switches are activated to adjust the time and date.

This proposed system uses a microcontroller of the PIC16F series family and a rectified-power supply. In this system, number of switches are arranged to adjust the time and date. Adjusted data will store in the RTC IC that adjusted data is right data that shows on 16×2 LCD display is interfaced to the microcontroller for displaying the information.

This project in future can be enhanced by interfacing a GSM modem to the micro controller, so that a warning message is sent to the concerned authorities via SMS.

HIGHLIGHTS

  • Digital clock using pic microcontroller
  • RTC IC is for store the adjusted time and date
  • 16*2 LCD display is used to show information

BLOCK DIAGRAM

HARDWARE REQUIREMENTS

  • PIC CONTROLLER
  • RTC IC
  • LCD display
  • CMOS cell
  • Switches
  • Transformer

SOFTWARE REQUIREMENTS

  • micro c
  • Eagle
