COIN BASED MOBILE CHARGER

Code 256 COIN BASED MOBILE CHARGER

6,000.00 3,800.00

The main objective of this project is to develop Coin based mobile charger by using a Timer IC along with circuits of IR sensor which we putting the coin inside it and relay of the charger is automatically ON for particular time.

Kits DescriptionPrice
If You Are An Enthusiast

Do It Yourself Kit
Ready-made Project,PCB,Components,Circuit Diagram,Program,Report,Explanatory Video

6,400.00 4,200.00
If You Are Short On Time

Ready-made Kit
Ready-made Project,Circuit Diagram,Program,Report,Explanatory Video

6,000.00 3,800.00
For Institutions

Project Kit
PCB,Components,Circuit Diagram,Program,Report,Explanatory Video

5,200.00 3,600.00
For Documentation

Documentation
Circuit diagram,Program,Report,Explanatory Video

1,800.00 1,500.00
For PCB

PCB
PCB,Circuit Diagram

1,200.00 1,000.00

Description

The main objective of this project is to develop Coin based mobile charger by using a Timer IC along with circuits of IR sensor which we putting the coin inside it and relay of the charger is automatically ON for particular time.

An arrangement operates user putting their coin inside IR sensor which are placed opposite to each other Rx and Tx. while coin is putted in it the ray will break and comparator signal gives to timer IC which interfaced to taking as input. As soon as coin inserted the relay will ON like this time set by preset value. Now days it is necessary because everyone is having his own mobile and person is in the unknown placed then this system will works properly. Instead of asking anyone it’s better to put coin and charge mobile. This project is more helps for the passengers to develop and placed in bus stand, railway station etc. A standard power supply is used. A buzzer indicates the charging time is beginning and LED indicates charging is ON/OFF.

HIGHLIGHTS

  • The main objective of this project is to develop Coin based mobile charger by using a Timer IC
  • Now days it is necessary because everyone is having his own mobile
  • Instead of asking anyone it’s better to put coin and charge mobile
  • This project is more helps for the passengers to develop and placed in bus stand, railway station etc
  • A standard power supply is used

BLOCK DIAGRAM

HARDWARE REQUIREMENTS

  • Timer IC
  • IR sensor
  • Transformer
  • Voltage regulator circuit
  • Buzzer
  • 555 IC

SOFTWARE REQUIREMENTS

  • Eagle
  • Proteus
