RF wireless controlled ROBOT

Code 6 RF wireless controlled ROBOT

5.00 out of 5
(3 customer reviews)

4,400.00 3,400.00

Ready-made Project

If You Are Short On Time
4,400.00 3,400.00
Add to cart - OR - See more options

The project is designed to control the ROBOT by using a RF technology for remote operation using an transmitter and receiver. The speed of the DC motor is directly proportional to the voltage applied across its terminals. Hence, if the voltage across motor terminal is varied, then the speed can also be varied.

Kits DescriptionPrice
Ready-made Project + DIY Project Kit
If You Are An Enthusiast
Ready-made project kit, One more extra bare PCB solderable components for extra PCB, All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, and One year warranty. 5,400.00 4,400.00
Ready-made Project
If You Are Short On Time
Ready-made project kit - All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, One year warranty. 4,400.00 3,400.00
DIY Project Kit
For Institutions
DIY KIT - Bare PCB, solderable components, external all components, All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, 3,400.00 2,400.00
For Documentation
(Report, PPT, Circuit diagram, Program code, Explanatory Video). Audio and video call support. 3,000.00 2,000.00
For Simulation
Proteus Simulation file, Program Coad, Hex File, Explanatory Video, Google Meet Or Zoom Meet Support. 4,000.00 3,000.00

Description

The project is designed to control the ROBOT by using a RF technology for remote operation using an transmitter and receiver. The speed of the DC motor is directly proportional to the voltage applied across its terminals. Hence, if the voltage across motor terminal is varied, then the speed can also be varied.

This project uses the above principle to control the speed of the motor by varying the duty cycle of the pulse applied to it (popularly known as PWM control). At the transmitting end using push buttons, commands are sent to the receiver to control the movement of the robot and make it move forward / backward and besides. An RF transmitter acts as a remote control that has the advantage of adequate range (up to 200 meters) with proper antenna. The receiver decodes the commands before feeding it to another DC motor via motor driver IC for necessary work. The average voltage given or the average current flowing through the motor will change depending on the duty cycle (ON and OFF time of the pulses), so the speed of the motor will change accordingly. The motor driver IC is interfaced to the decoder ic for receiving PWM signals and delivering desired output for speed control of the DC motor.

Furthermore, the project can be enhanced by using power electronic devices such as IGBTs to achieve speed control higher capacity industrial motors.

HIGHLIGHTS

  • Designed to control RF robot
  • RF technology for transmitter and receiver
  • Encoder for transmitter and Decoder for Receiver
  • Switches are used to control the direction

BLOCK DIAGRAM

HARDWARE REQUIREMENTS

  • RF Receiver
  • RF Transmitter
  • Encoder IC
  • Decoder IC
  • 9v battery
  • 12v battery
  • L293D ic
  • Motor
  • Wheel

SOFTWARE REQUIREMENTS

  • eagle
  • protious

RESOURCES

Additional information

Weight1.8 kg
Dimensions30 x 30 x 10 cm
