DISTANCE MEASUREMENT BY ULTRASONIC SENSOR

Code 02 DISTANCE MEASUREMENT BY ULTRASONIC SENSOR

5.00 out of 5
(1 customer review)

7,500.00 5,000.00

Ready-made Project

If You Are Short On Time
7,500.00 5,000.00
Add to cart - OR - See more options

The implementation of distance measurement system using ultrasonic wavesThe scope of the project in future can be heightened by using high-frequency transducers to make it fit for medical applications like ultrasound machine

Kits DescriptionPrice
Ready-made Project + DIY Project Kit
If You Are An Enthusiast
Ready-made project kit, One more extra bare PCB solderable components for extra PCB, All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, and One year warranty. 8,500.00 6,500.00
Ready-made Project
If You Are Short On Time
Ready-made project kit - All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, One year warranty. 7,500.00 5,000.00
DIY Project Kit
For Institutions
DIY KIT - Bare PCB, solderable components, external all components, All documentation (Report, PPT, Circuit diagram, Program code, explanatory video ), Audio and video call support, 6,500.00 4,800.00
For Documentation
(Report, PPT, Circuit diagram, Program code, Explanatory Video). Audio and video call support. 3,000.00 2,000.00

Description

This report details the implementation of distance measurement system using ultrasonic waves. As the human ear audible range is in between 20 Hz to 20 kHz, it is insensitive to ultrasonic waves that falls beyond that range, and hence, the ultrasound waves can be used for applications in industries or vehicles without hindering human activity. They are widely used as range meters and proximity detectors in industries and also in the parking assistance systems. The distance can be measured using pulse-echo and phase-measurement method. In this project, the pulse-echo method is used. The measurement unit uses pulses over continuous signal in the transmission frequency range of ultrasonic transducers. The signal is transmitted by an ultrasonic transducer, reflected by an obstacle and received by another transducer wherein the signal is detected. The time delay of the transmitted and the received signal corresponds to the distance between the system and the obstacle. The techniques of distance measurement using ultrasonic in air include continuous-wave and pulse-echo technique. In the pulse-echo method, a burst of pulses is sent through the transmission medium and is reflected by an object kept at a specified distance. The time taken for the pulse to propagate from the transmitter to the receiver is proportional to the distance of the object. In this project, an ultrasonic module is interfaced to the microcontroller, and an ultrasonic transducer comprising of a transmitter and receiver are also used. The transmitted waves are reflected back from the object and received by the transducer. The total time taken from sending the waves to the receiving end is calculated by taking into consideration the velocity of the sound. Then, the distance is calculated by a program running on the microcontroller and displayed on an LCD screen interfaced to the microcontroller. The power supply consists of a step-down transformer 230/12V, which steps down the voltage to 12V AC. This is converted to DC using a Bridge rectifier. The ripples are removed using a capacitive filter, and it is then regulated to +5V using a voltage regulator 7805, which is required for the operation of the microcontroller and other components. The scope of the project in future can be heightened by using high-frequency transducers to make it fit for medical applications like ultrasound machine.

HIGHLIGHTS

  • pulse-Echo method is used
  • High-Frequency transducers
  • Distance is calculated by program running on the microcontroller
  • No need to any mechanical connection

BLOCK DIAGRAM

HARDWARE REQUIREMENTS

  • Microcontroller
  • Ultrasonic sensor
  • LCD Display
  • Buzzer
  • Transformer

SOFTWARE REQUIREMENTS
proties

  • Keil
  • Eagle
  • proties
